Industrial Kilns & Muffle Furnaces Professional MT-Series Furnaces for Ceramics, Photoceramics & Glass
MARKITON offers a complete line of industrial-grade MT-Series muffle furnaces, engineered for stable, safe and precise firing of ceramics, photoceramic portraits, glass, and other heat-resistant materials.
From the compact MT50 to the high-capacity MT150, all kilns are built for continuous operation, exceptional durability and minimal maintenance.
Manufactured to European industrial standards, MARKITON muffle furnaces are ideal for photoceramic studios, educational centers, laboratories and production facilities.
Key Advantages of MARKITON Muffle Furnaces
Heavy-Duty Steel Construction
The outer body is made of stamped sheet steel with powder coating:
- corrosion protection
- high mechanical strength
- clean, modern design
- easy-to-clean smooth surfaces
High-Density Ceramic Fiber Chamber
The firing chamber is made entirely of high-density refractory ceramic fiber, ensuring:
- reduced energy consumption
- fast heating and cooling
- uniform temperature distribution
- low external surface temperature
Kanthal A1 Heating Elements
All MT-Series furnaces use genuine Kanthal A1 resistance coils — the industry’s leading material:
- extended service life
- excellent performance at high temperatures
- high firing precision and temperature stability
Multi-Stage Digital Controller
The advanced controller allows:
- multi-step firing profiles
- adjustable hold times
- automated heating and cooling cycles
Perfect for photoceramic firing curves and artistic ceramic workflows.
Enhanced Ventilation & Corrosion Protection
- multiple air intake channels for improved airflow
- internal ventilation to extract moisture
- overheating prevention for the metal casing
These features significantly increase kiln longevity.
Manual Chimney / Vent Port
Located at the center of the roof:
- releases moisture at the beginning of the cycle
- accelerates cooling after firing
Full Safety System
- micro-switch cuts power when the door is opened
- red safety latch prevents accidental opening
- rounded edges and reinforced hinges
Safety is always the top priority.
Technical Specifications — MT-Series Muffle Furnaces
| Model | Chamber Volume | Max Temp | Internal Dimensions | External Dimensions | Power | Voltage | Weight |
|---|---|---|---|---|---|---|---|
| MT50 | 50 L | 1100°C | 420×350×350 mm | 770×790×740 mm | 2.5 kW | 230 V | 85 kg |
| MT70 | 70 L | 1100°C | 430×400×400 mm | 770×790×740 mm | 2.8 kW | 230 V | 85 kg |
| MT85 | 85 L | 1100°C | 430×450×450 mm | 800×820×750 mm | 3.1 kW | 230 V | 90 kg |
| MT100 | 100 L | 1100°C | 600×400×400 mm | 900×850×800 mm | 4.5 kW | 230/400 V | 120 kg |
| MT150 | 150 L | 1100°C | 600×500×500 mm | 950×880×850 mm | 6.0 kW | 230/400 V | 150 kg |
Transport pallets available:
Standard: 90×90×90 cm
MT100: 100×90×90 cm
MT150: 105×90×90 cm
Applications of MARKITON Muffle Furnaces
Photoceramics
Firing MARKITON LX / FX / GX ceramic toners.
Art Ceramics & Clay
Ceramic pieces, clay works and artistic firing.
Glass Fusing & Slumping
Glass shaping, decorative glass and heat processing.
Laboratory Processes
Controlled heating for educational centers and laboratories.
Enamels, Metals & Powders
Enamels, metals and powder materials for sintering.
MT-Series furnaces are suitable for both small studios and industrial workshops thanks to their energy efficiency and long-term continuous operation capability.
